The STABILA 04500TR LAR 160 G 600-metre Green Line Rotary Laser Kit with Tripod, Digital Receiver and Elevation Rod (6-Piece) is the right rotation laser for you if you need to work precisely. Quick to set up and easy to operate, the laser really comes into its own when used over large distances and linked to a receiver. All in all, it is a high-quality product that delivers precise results. High-performance receiver â€“ large working area of up to 600 m in diameter.

Application examples: For a wide range of tasks in drywall construction â€“ for layout work, when positioning partition walls and suspending ceilings. Transfer heights quickly and easily in electrical installation work â€“ align plug sockets, switches and cable ducts horizontally and vertically with one another. For installation work in industrial construction â€“ measure planes and determine alignments for routing lines and pipes. In industrial assembly applications â€“ measure and align shelving systems in logistics areas.

Features

Fully automatic, motor-driven rotation laser â€“ high levelling accuracy of Â± 0.1 mm/m, fast self-levelling function within 20 seconds
STABILA GREENBEAM technology for improved visibility of the rotating laser beam â€“ green laser beams are four times more visible to the human eye than red beams
Four laser functions for versatile use â€“ horizontal and vertical rotation, plumb-line function and right angle (90Â°) in vertical operation
Protection class IP 65 â€“ dustproof and waterproof
Shock-absorbent STABILA soft grip casing provides protection against impacts â€“ the stable housing cover also protects the laser optics
Easy to use via three control buttons â€“ on/off, tilt mode, manual mode
Battery drawer â€“ easy replacement, even directly on the tripod
Large working area with REC 160 R/G set receiver â€“ up to 600 m in diameter
Two 5/8 in. threads integrated in the housing
Target plate with magnetic holder and cross-hair
Stable carrying case
Weatherproof â€“ waterproof and dustproof in accordance with protection class IP 65

Includes

Target card
Receiver with clamp
Target plate
Manual & kit box
Tripod
Grade Rod

Specifications

Laser class	2
Output	< 1 mW
Laser wavelength	510 - 530 nm
Self-levelling range	+/-5Â°
Levelling accuracy	+/-0.10 mm/m
Diameter of working area for set receiver	600 m
Operating life	20 h
Battery Type	D
Protection Class	IP 65
Tripod Connection	5/8 in.
Package Length	54.3 in.
Package Width	24.05 in.
Package Height	9.35 in.
Package Weight	36.4 lb.
